PLATES
Stainless Steel, Duplex & High-Nickel Alloy Plates for Industrial Applications
Steel Plates are supplied for demanding fabrication, process equipment and engineered applications where dependable material performance, dimensional consistency and corrosion resistance are important. The 4 mm to 40 mm thickness range supports both general fabrication and heavier industrial requirements.
Available in stainless steel, duplex and super duplex stainless steel, and selected high-nickel alloys, plate supply can be aligned with the required grade, thickness, width, length, surface condition and heat-treatment requirement. Material options include SS 304/304L, SS 316/316L, Duplex 2205, Super Duplex 2507 and selected nickel-alloy grades.
Supply options can be aligned with the required material specification, thickness, dimensions, finish, quantity and end-use application, subject to final technical and commercial confirmation.
01
4-40 MM RANGE
Plate thickness options for varied industrial requirements.
02
CORROSION RESISTANCE
Stainless, duplex and nickel-alloy material options.
03
FABRICATION READY
Suitable for cutting, forming, welding and machining.
04
CUSTOM SUPPLY
Grades, sizes and supply conditions to suit requirements.
PRODUCT DETAILS
Specifications and Typical Applications
| Specification | Details |
|---|---|
| Product Type | Steel Plates |
| Material | Stainless / Duplex / Super Duplex / High Nickel |
| Representative Grades |
SS 304/304L, 316/316L Duplex 2205, Super Duplex 2507 Alloy 600, 625, 800/800H/800HT, 825 Alloy 400 (Monel 400) |
| Applicable Standards |
ASTM A240/A240M & ASTM A480/A480M – Stainless Steel, Duplex & Super Duplex Plates ASTM B127 – Alloy 400 / Monel 400 ASTM B168 – Alloy 600 ASTM B443 – Alloy 625 ASTM B409 – Alloy 800 / 800H / 800HT ASTM B424 – Alloy 825 |
| Thickness Range | 4–40 mm |
| Width / Length | Standard or customized dimensions |
| Surface Finish | Hot Rolled / No.1 / Pickled / Polished as applicable |
| Flatness / Tolerance | Applicable standard / agreed requirement |
| Supply Condition | Solution Annealed / Heat Treated / As agreed |
Standards listed are applicable according to material grade, product form and supply condition. Final grade, standard, dimensions and testing requirements should be confirmed at the time of enquiry/order.
TYPICAL APPLICATIONS
- Pressure vessels and process equipment
- Chemical and petrochemical equipment
- Heat exchangers and storage systems
- Marine and offshore fabrication
- Industrial tanks, ducts and structural parts
- General engineering and heavy fabrication
WHY CHOOSE THIS PRODUCT
✓ 4-40 mm thickness range
✓ Stainless, duplex and high-nickel alloy options
✓ Suitable for demanding corrosion-resistant service
✓ Standard or customized dimensions and finishes
LOOKING FOR STEEL PLATES?
Share your required grade, thickness, width, length, standard, finish and quantity with our team.
